截面圖 Section | 型號 Model | 規(guī)格 Specificationn/φmm | 單芯導體截面積 EachCrossec Areaφmm | 20℃時導體最大直流電阻 Conductor'sMaxDC Resistanceat20℃Q/km | 70℃時最小絕緣電阻MinimumInsulatingResistanceat70℃M Q/km | 屏蔽密度 Shield Density % | 標稱外徑 Nom.0.D φmm |
| DMSP200 | 2x[(15/0.12錫絲+2/0.10A)+SP]+96/0.12 銅絲繞包 | 0.20 | 120 | 0.016 | >90 | 6.0 |
DMSP220 | 2x[(26/0.10+2/0.10A)+SP]+96/0.12銅絲繞包 | 0.22 | 92.3 | 0.015 | >90 | 6.5 | |
DMSP310 | 2x[(37/0.10+2/0.10A)+SP]+128/0.10銅絲繞包 | 0.31 | 69.2 | 0.014 | >90 | 7.0 | |
DMSP380 | 2x[(45/0.10+2/0.10A)+SP]+128/0.10銅絲繞包 | 0.38 | 55.0 | 0.013 | >90 | 7.5 | |
DMSP500 | 2x[(28/0.15+2/0.10A)+SP]+144/0.10銅絲繞包 | 0.50 | 39.0 | 0.012 | >90 | 8.0 | |
YM220 | 2x(20/0.12+SP+45/0.10銅絲繞包) | 0.22 | 92.3 | 0.015 | >90 | 6.5 |
●線芯導體為4N無氧銅絞束而成，抗氧化，訊號導通率高，衰減小。
●此型號線適用傳輸?shù)皖l小信號用線連接，俗稱話簡線，此型號通過2次屏蔽使線材屏蔽能力更強，外護套為彈性體聚氯乙烯，手感柔軟，色彩鮮艷，耐扭曲， 不脆化。 (低溫沖擊脆化溫度可達-30℃)
●The Cable has stranded 4Noxygen-fre copperwire asthe core conductor,which resistsoxidation,ensureshigh transmission rate and low attenuation.
●Such cable can be used forthe transmision o lowfrequency signals,whenthey are usually alled microphone cables.Thisitem with twiceshield,the cable shield
more stronger,The protective sheathsare made ofelastic polyinyiPVC)in brightolors which are sof,distortion endure,and hard to go brite(oritl temperature:-30℃)
