截面圖 Section | 型號 Model | 規格 Specificationn/φmm | 單芯導體截面積 EachCrossecAreaφmm | 20℃時導體最大直流電阻 Conductor'sMaxDC Resistanceat20℃Q/km | 70℃時最小絕緣電阻 MinimumInsulating Resistanceat70℃M Q/km | 屏蔽密度 Shield Density % | 標稱外徑 Nom.0.Dφmm |
雙并RCA | DR140 | 2x(12/0.12+32/0.12銅絲繞包) | 0.14 | 92.3 | 0.015 | ≥90% | 4+4 |
DR220 | 2x(28/0.10+64/0.10銅絲繞包) | 0.22 | 92.3 | 0.015 | ≥90% | 4.3+4.3 | |
DR230 | 2x(28/0.10+64/0.10銅絲繞包) | 0.22 | 92.3 | 0.015 | ≥90% | 5.5+5.5 | |
DR240 | 2x(20/0.12+40/0.12銅絲繞包) | 0.22 | 92.3 | 0.015 | ≥90% | 5.5+5.5 | |
圓形RCA | DR160 | 2x[(2x20/0.10+6/0.20錫絲)+AL]+尼龍編織 | 0.16 | 0.85 | 0.017 | ≥90% | 6.5 |
●線芯導體為4N無氧銅絞束而成，抗氧化，訊號導通率高，衰減小。
●此型號線適用傳輸?shù)皖l小信號用線連接，纏繞屏蔽相對編織屏蔽更為柔軟，外護套為彈性體聚氯乙烯，手感柔軟，色彩鮮艷，耐扭曲，不脆化。(低溫沖擊 脆化溫度可達-30℃)
●The Cable has stranded 4Noxygen-free copperas the core conductor,which resists oxidation,ensures high transmission rate andlow atenuation.
●Such cables are usedforthetransmision oflow frequency signals,Spiral shieldis even softer than braid shield,The elastic protective jackets are made of polyvinyl chloride in bright colors which are soft,distortion endure,and hard to go brittle.(brittle temperature:-30℃
